5GM-ANT-M670-BB-6CG

Cellular Frequency Range and Efficiency

617-960 MHz > 65%

1710-3800 MHz > 75%

4900-6000 MHz > 85%

GNSS Frequency Range

1562-1612 MHz

VSWR

< 2.0:1

Operating Temperature

-40°C to +80°C

Ingress Protection

IP69K

Cable Length

15 ft (4.5 m)

Antenna Housing

High Impact ABS polymer

Dimension

114 x Φ140 mm

Radiation Pattern

Omni Directional
